Rfwel :: WiMax :: 2.5 GHz WiMax Radio Modem :: WiMax Outdoor CPE 2.496-2.69 GHz

WiMax Outdoor CPE 2.496-2.69 GHz

Gemtek ODU (out-door unit) 802.16e Wave2 Compliant Outdoor CPE features dual polarization antenna to provide MIMO technology, both Matrix-A and Matrix-B. Combined with powerful RF circuit design, highly Integrated SW and robust outdoor environmental enclosure, the ODU-Series outdoor modem serves best- in-class outdoor coverage and throughput.

Uses Sequans SQN1130 chipset offering low power, high throughput, MIMO, hybrid ARQ category 1-4 for WiMAX mobile stations.

Key Features:

Fully 16e wave2 Feature support
Robust Environmental Design
Best-in-class Radio Performance
Multiple QoS Support
Highly integrated SW features
Frequency: 2.496-2.69GHz
Transmit Power: 27dBm
Antennas: 2x 12.5dBi integrated antennas (no external antenna port)
1 RJ45 10/100 Ethernet port
POE powered
Modulation QPSK/ 16QAM/ 64QAM (downlink only)

Quick Links

Detailed Specifications

Remote Wireless Video Surveillance

Sample Engineering Drawings

Select Case Studies

Compare 2.5GHz WiMax Antennas

Discuss in the Forums (user community input)

Broadband Wireless Resources

Ask a Question

Details

SKU WIXS-167

Our price: $424.99
