MBR1400 - Mission-Critical Broadband Router
features: VPN, LTE Support, 4G/3G, Private + Guest Networks, 750+ feet of WiFi
CradlePoint's Mission-Critical Broadband Router (MBR1400) takes the power and flexibility of our industry leading router, and when combined with an active high-speed wireless broadband data connection, gets your business network online in no time.
Designed for small business, branch office, and retail locations - our business series router provides a secure primary or backup connection to the internet. In addition to connection options for traditional wired networking solutions like Cable, DSL, or T1, the most powerful feature of the MBR1400 is its ability to use USB or ExpressCard Data Modems to create instant networks anywhere you receive a broadband signal.
use with: LTE, WiMAX, CDMA (EVDO, 1xRTT), GSM (EDGE, GPRS, HSPA, HSPA+), Cable, and DSL modems
ENTERPRISE PERFORMANCE
-
Targeted for retail locations, branch offices, or small and medium sized businesses
-
Works with high-performance Business-Grade Modems
-
Load balance multiple data modems or wired data services
-
Compatible with Cisco, Juniper, and other industry-leading network hardware providers
ENHANCED WI-FI
-
750+ feet of WiFi Range
-
Enhanced performance around walls and other obstructions
-
Dual band WiFi broadcast - either 2.4GHz or 5.0GHz
-
Maximum security with both Public and Private networks
ADDITIONAL FEATURES
-
Dual-band WiFi, 3x3 MIMO Antenna Subsystem, removable external antennas, dual SSIDs
-
Plug-and-Play support for over 120 broadband data modems, allowing for site-specific carrier/service selection for broadest deployment
-
Standardized platform and centralized remote management
-
Up to 20 concurrent VPN endpoint sessions
-
Compatible with Cisco, SonicWall, and other VPN termination systems
-
Establish continuous uptime with optimum total cost of ownership for broad deployment
-
Simple to install, configure and maintain with minimal impact on IT
|
Public/ Private WiFi Hotspot w/ Cellular, WiMax, LTE, Broadband Backhaul
|
 |
Cradlepoint MBR1400 Captive Portal Feature Overview
|
Technical Specifications
|
|
Ports |
|
Modem Ports
|
2 ExpressCard and 3 USB 2.0 for 3G/4G modems
|
|
LAN/WAN
|
5 configurable 10/100/1000 Ethernet LAN/WAN ports (default 1WAN, 4 LAN)
|
|
WiFi & WiFi Security |
|
802.11n 3x3 MIMO with support for legacy 8702.11b/g |
|
2 SSID's to support multiple users or QOS categories |
|
Switchable 2.4/5.8GHz radio configuration (802.11a for 5GHz) |
|
Support for up to 128 concurrent users |
|
WiFi as WAN (for WiFi extension of WiFi-to-Ethernet Bridge) |
|
WEP/WPA/WPA2 (AES), 802.11 Authentication, SSID broadcast disable, Captive Portal Option |
|
WAN Connection Types, Redundancy & Load Balancing |
|
Static IP, DHCP, PPPoE, Cellular Modem PPP Authentication, Sprint MPLS |
|
Failover/Failback (4G/3G/Ethernet) |
|
Load Balancing |
|
WAN Failure Detection via Ping (Ethernet) |
|
Environmental |
|
Temperature |
32oF -104oF operating
-4oF - 158oF storage |
|
Relative Humidity |
10%-85% operating
5% - 90% storage |
|
Dimension |
9" x 5.1" x 1.57" |
PACKAGE CONTENTS
-
MBR1400 Gigabit router
-
AC/DC Power Supply
-
Ethernet Cable & Mounting Screws
-
3 Removable High-Gain External 2.4GHz WiFi Antennas (RP-SMA)
-
Quick Start Guide w/ Warranty Information
|
|
