| Image |
Antenna Specs |
Where to Buy Antenna |
AT&T LTE |
Verizon LTE |
Sprint LTE |
T-Mobile LTE |
| Multi-band LTE Antennas |
| |
| Multi-band LTE Directional Panel Antennas |
 |
15 dBi, 698-960 / 1700-2700 MHz
(RFWP072515D)
|
|
 |
|
|
|
 |
12 dBi, 698-960 / 1710-2700 MHz
(RFWPO72712D)
|
|
|
|
|
|
 |
10 dBi, 698-960 / 1700-2700 MHz
(RFWLTWPA10NF)
|
|
|
|
|
|
 |
8 dBi, 698-960/ 1710-2700 MHz
(M5277i)
|
|
|
|
|
|
 |
3 dBi, 698-960 MHz, 1710-2700 MHz
(WMM-7-27)
|
|
|
|
|
|
| Multi-band LTE Directional Yagi Antennas |
 |
12 dBi, 698-960 / 1710-2700 MHz
(RFWY072712D)
|
|
|
|
|
|
 |
11 dBi, 698-960/ 1710-2700 MHz
(TS221171)
|
|
|
|
|
|
 |
9 dBi, 806-960 / 1710-2500
(MB825)
|
|
 |
|
|
|
| Multi-band LTE Low-Profile Mobile Antennas |
 |
694-894/ 1700-2700 MHz
(MGRM-WLF-1C10)
|
|
|
|
|
|
 |
698-960, 1710-2500 (2 cables, FME-Female)
1575.42 - GPS (1 cable, SMA-Male)
(GPSDM700/2500FFS)
|
|
|
|
|
|
|
Cable1: 698-2700 MHz (Cellular/LTE/AWS) (SMA-Male)
Cable2: 2400-2485/ 5150-5875 MHz (WiFi) (RP-SMA-Male)
Cable3: 1575.42 MHz (GPS) (SMA-Male)
(GPSDM700/5800GGT)
|
|
|
|
|
|
 |
750-1250 MHz, 1650-2700 MHz
(RMM-UMB-1C )
|
|
|
|
|
|
 |
Cable 1 & 2 : 694-960 / 1710-2170 MHz (LTE) (SMA-Male)
Cable 3: GPS (SMA-Male)
(LTM301-3C3C2C-BLK-180)
|
|
|
|
|
|
 |
Cable 1 & 2 : 694-960 / 1710-2170 MHz (LTE) (SMA-Male)
Cable 3 : 2400-2500 / 4900-6000 MHz (WiFi) (SMA-Male)
Cable 4: GPS
(LTM401-3C3C3C2C-BLK-180)
|
|
|
|
|
|
 |
Cable 1 & 2 : 694-960 / 1710-2170 MHz (LTE) (SMA-Male)
Cable 3 & 4: 2400-2500 / 4900-6000 MHz (WiFi) (RP-SMA-Male)
Cable 5: GPS (SMA-Male)
LTM501-3C3C3J3J2C-BLK-180 (See also LTM501-3C3C3C3C2C-BLK-180 with all SMA-Male cables)
|
|
|
|
|
|
 |
690-960/ 1452-1492/ 1710-2500
(RFWAT06252_5XD)
|
|
|
|
|
|
 |
694-894, 1700-2700 MHz
(RM-WLF-DN)
|
|
|
|
|
|
 |
Cable 1: 694-894 MHz, 1.7-2.7 GHz (LTE) (SMA-Male)
Cable 2: 2.4 GHz, 4.9-6 GHz (WiFi, Public Safety, DSRC) (SMA-Male)
Cable 3: GPS (SMA-Male)
(SMW-305-3C3C2C)
|
|
|
|
|
|
| Multi-band LTE Desktop Antennas |
 |
698-960 / 1710-2700 MHz (TS9 or SMA-M connectors)
(DMM-7-27-2TS9, DMM-7-27-2SP)
|
|
|
|
|
|
| Multi-band LTE Omnidirectional Antennas |
 |
9 dBi, 690-2700 MHz
(1273-PB)
|
|
|
|
|
|
 |
9 dBi, 824-960/ 1710-2700 MHz
(295-PW)
|
|
|
|
|
|
| Multi-band LTE Indoor Dome Antennas |
 |
7 dBi, 698 - 2700 MHz
(RFWD072707DNF)
|
|
|
|
|
|
 |
7 dBi, 698 - 2700 MHz, Low Profile
(02121261-05606U)
|
|
|
|
|
|
 |
824-2700 MHz
(RFWAT0P82P7DNF)
|
|
|
|
|
|
| |
| Lower 700 MHz LTE Antennas |
| Lower 700MHz band includes: LTE Band 12 = 699 – 746 MHz; LTE Band 17 = 704 – 746 MHz. Used by AT&T, Rogers, T-Mobile, and U.S. Cellular. Note that Band 17 is a subset of Band 12 (so any Band 12 antenna will work with Band 17 LTE devices) |
| Lower 700 MHz LTE Panel Antennas |
 |
9 dBi, 694-806 MHz
(PN9-700)
|
|
|
|
|
|
 |
6 dBi, 694-960 MHz
(OD6-700)
|
|
|
|
|
|
|
4 dBi, 694-960 MHz
(OD4-700)
|
|
|
|
|
|
| Lower 700 MHz LTE Yagi Antennas |
|
11 dBi, 698-960/ 1710-2700 MHz
(TS221171)
|
|
|
|
|
|
| |
| Upper 700 MHz LTE Antennas |
| LTE Band 13 = 746 – 787 MHz. Used by Verizon Wireless, Telus, and MTS in North America. Note that LTE Band 14 (758 – 798 MHz) is a US Public Safety band. |
| Upper 700 MHz LTE Panel Antennas |
 |
10 dBi, 746-787 MHz
(RFWAT07PNF)
|
|
|
|
|
|
|
9 dBi, 694-806 MHz
(PN9-700)
|
|
|
|
|
|
| Upper 700 MHz LTE Yagi Antennas |
 |
11 dBi, 746-787 MHz
(RFWAT07YNF)
|
|
|
|
|
|
 |
14 dBi, 745-806 MHz
(BMYD745M)
|
|
|
|
|
|
| Upper 700 MHz LTE Omni Antennas |
|
6 dBi, 694-960 MHz
(OD6-700)
|
|
|
|
|
|
|
4 dBi, 694-960 MHz
(OD4-700)
|
|
|
|
|
|
| |
| 2500 MHz LTE Antennas |
|
Band 38 is IMT-E and operates with TDD at 2600MHz. Band 41 is the BRS/EBS band and also operates in TDD mode at 2500MHz.
|
| 2500 MHz LTE Panel Antennas |
 |
18.3 dBi, 2500 - 2700 MHz
(RFW-PA2518B01)
|
|
|
|
|
|
 |
8 dBi, 2300-2700 MHz
(RFWAT2P5INPANNF)
|
|
|
|
|
|
 |
14 dBi, 2500 - 2700 MHz
(HG2614P-NF)
|
|
|
|
|
|
 |
17.5 dBi, 2300-2700 MHz
(PTWLSP2327-18XP60NUF)
|
|
|
|
|
|
| 2500 MHz LTE Mobile Antennas |
 |
2300-2700 MHz
(RFWAT2P5MMSM)
|
|
|
|
|
|
 |
2100-2700/ 3300-3800 MHz
(SMD-3500-3C3C)
|
|
|
|
|
|
 |
2100-2700/ 3300-3800 MHz
(SMD-3500-3C3C3C)
|
|
|
|
|
|
 |
6 dBi, 2500-2700 MHz
(ECOS6-2600)
|
|
|
|
|
|
 |
2300-2700 / 3300-3900 MHz
(RFWRD2435RPS)
|
|
|
|
|
|
| 2500 MHz LTE Omni Antennas |
 |
8.5 dBi, 2500-2700 MHz
(HG2609U)
|
|
|
|
|
|
|
824-2700 MHz
(RFWAT0P82P7DNF)
|
|
|
|
|
|
| 2500 MHz LTE Yagi Antennas |
 |
8 dBi, 824-960/ 1710-2690 MHz
(RFWAT2P5LPDANF)
|
|
|
|
|
|
| 2500 MHz LTE Desktop Antennas |
|
698-960 / 1710-2700 MHz (TS9 or SMA-M connectors)
(DMM-7-27-2TS9, DMM-7-27-2SP)
|
|
|
|
|
|
| |
| 850/1900 MHz Antennas |
|
The below antennas are suitable for 3G ONLY except for Sprint 4G LTE at former PCS band 1850-1990 MHz. View additional antennas here
|
| 850/1900 MHz Mobile Antennas |
 |
6 dBi, 806-894 / 1850-1990 MHz
(301103)
|
|
3G |
3G |
|
3G |
 |
6 dBi, 806-894 / 1850-1990 MHz
(301130)
|
|
3G |
3G |
|
3G |
 |
3 dBi, 824-2500 MHz
(MAF94300)
|
|
3G |
3G |
|
3G |
| |
| 3.5/ 3.65 GHz Antennas |
View additional 3500 MHz antennas here. 3550 - 3700 MHz Antennas can be used for the new CBRS band learn more |
| 3500 MHz Mobile Antennas |
|
2100-2700/ 3300-3800 MHz
(SMD-3500-3C3C)
|
|
|
|
|
|
|
2100-2700/ 3300-3800 MHz
(SMD-3500-3C3C3C)
|
|
|
|
|
|
 |
3400-3600 MHz
(HG3505RD-RSP)
|
|
|
|
|
|
|
2300-2700 / 3300-3900 MHz
(RFWRD2435RPS)
|
|
|
|
|
|
| 3500 MHz Panel Antennas |
 |
19 dBi, 3300-3800 MHz
(ARC-VS3518SV1)
|
|
|
|
|
|
| 3500 MHz Omni Antennas |
 |
11.6 dBi, 3400-3700 MHz
(HG3512UP-NF)
|
|
|
|
|
|
 |
9 dBi, 3300-3800 MHz
(S3307BPNF)
|
|
|
|
|
|
| 3500 MHz Dish/ Grid Antennas |
 |
26 dBi, 3600-3800 MHz
(T35260G10006)
|
|
|
|
|
|
